Description
Thanks to their ultra-compact footprint, Samsung ducted units slot into any space. The 20/25 kW versions split into two modules, speeding up setup and servicing. Top, bottom or side entry to the indoor section keeps maintenance hassle-free.
Supply-air temperature control
Ducted indoor units—aka HVAC kits—track supply-air temperature for extra comfort without touching outdoor-unit settings. Heating or cooling modes are tweaked through the remote, working with every ducted or HVAC system.
Auto external static pressure (ESP) tuning
Automatic external static pressure tuning fine-tunes fan performance, striking the sweet spot between quiet and efficient. The feature is simple to switch on; ask your Samsung rep for compatible models.
Technical specs
- External static pressure 0–14 mmAq.
- Electronic expansion valve (EEV) for precise refrigerant control.
- Washable long-life filter.
- Built-in auto-restart.
- Condensate drain pump (750 mmH₂O).
Kit contents
- 1 reversible indoor unit
- 1 reversible outdoor unit
- 1 MWR-WG00JN remote
- 1 user manual
Additional information
| TÉLÉCOMMANDE : | |
|---|---|
| WIFI : |
Product details
AC120RNMDKG / AC120RXADNG / No WiFi-MWR-SH00N
0.00 Kg
Data sheet - The information presented is for reference only. It must always be verified. Climaled accepts no liability for errors or misinterpretation.
- Air-conditioning System
- Mono-split
- Indoor Unit Type
- Ducted
- Room (m²)
- 120
- WiFi
- Optional
- Power
- 12.5 kW / 45000 BTUs
- Rated heating power
- 13.2 kW
- Rated cooling power
- 12 kW
- Cooling energy class
- A+
- Heating energy class
- A+
- SCOP / Rated heating energy label
- 4
- SEER / Rated cooling energy label
- 5.8
- Refrigerant
- R32
- Refrigerant line
- 3/8'' - 5/8''
- Voltage
- Three-phase
- Min sound pressure dB(A)
- 30
- Indoor unit dimensions (mm)
- 1300 x 300 x 700
- Outdoor unit dimensions (mm)
- 940 x 998 x 330
Specific references
- EAN13
- 8801643769628
