Description
How it works
The outdoor unit harvests energy from the air to deliver heating, cooling and hot water. Up to 75 % of the energy is drawn from the air, the remainder supplied by electricity. The air-to-water heat pump uses a compressor and refrigerant to transfer this energy to the water, heating it as required before circulating it throughout your home.
Low-temperature heat pump
Engineered for new builds, these units suit underfloor heating or low-temperature fan convectors, needing lower flow temperatures to match the comfort of classic radiators.
Refrigerant-linked connection
Split heat pumps pair an outdoor air-capture module with an indoor control hub. A sealed refrigerant line keeps heat loss minimal while moving warmth inside.
Key highlights
- All hydraulic parts built-in, no extra components needed.
- Front-facing hydraulic parts for quick servicing.
- Space-saving footprint fits tight spots, zero side clearance.
- Sleek look that blends with household appliances.
- Pairs with stainless-steel tank or ECH2O tank.
- Reliable heat extraction down to –25 °C.
- Control via Daikin Residential Controller app.
- Built-in voice control.
Additional information
| TÉLÉCOMMANDE : |
|---|
Product details
ERGA06EV / EHVH08S23E9W
20.00 Kg
Data sheet - The information shown is for documentation purposes only. It must therefore always be verified. Climaled cannot be held liable for any error or misinterpretation.
- Capacity
- 6 kW / 22000 BTU
- Nominal heating capacity
- A7/W35: 6 kW – A7/W45: 5.9 kW
- Operating mode
- Heating only
- Integrated tank
- Yes
- Refrigerant
- R32
- Refrigerant connections
- 1/4'' – 5/8''
- Power supply
- Three-phase
- Energy class water 35 °C
- A++
- Energy class water 55 °C
- A+++
- SCOP – Water outlet 35 °C
- 6.28
- SCOP – Water outlet 55 °C
- 4.03
- Min. sound pressure dB(A)
- 28
- Tank capacity (litres)
- 230
- Indoor unit dimensions (mm)
- 1850 x 595 x 625
- Outdoor unit dimensions (mm)
- 740 x 884 x 388
