Description
The Daikin Altherma 3 M is a third-generation monobloc heat pump that runs on R-32 refrigerant. Offered in outputs from 9 to 16 kW, it fits both new-build and retrofit projects.
Sleek & discreet look
A horizontal black front grille hides the single fan, cutting perceived noise, while the light-grey cabinet blends into any setting.
Smarter airflow
One larger fan replaces the usual twin set-up, engineered for quieter operation and smoother air movement.
Next-gen R-32 refrigerant
As the pioneer of R-32 heat pumps, Daikin delivers a low-impact solution that boosts energy efficiency, lowers CO2 emissions and meets easy-recycling EU rules.
Space-saving package
The all-in-one outdoor unit needs no indoor module and can tuck beneath a window, freeing up exterior space.
Hassle-free fitting
Built-in hydraulic parts make install and service of the Daikin Altherma 3 M quick and simple.
User advantages
- Single-box unit with all hydraulics inside
- Option to connect domestic hot water
- W-LAN adapter ready
- Eco-efficient heating & cooling via air-to-water heat pump
- Built-in electric backup for extreme cold
Additional information
| TÉLÉCOMMANDE : |
|---|
Product details
EDLA04E3V3 / MMI
91.00 Kg
Data sheet - The information provided is for documentation purposes only. It must always be verified. Climaled accepts no liability for errors or misinterpretation.
- Capacity
- 4 kW / 14000 BTUs
- Rated heating capacity
- A7/W35: 4.3 kW – A7/W45: 4.6 kW
- Operating mode
- Heating only
- Refrigerant
- R32
- Power supply
- Single-phase
- Energy class water 35°C
- A+++
- Energy class water 55°C
- A++
- SCOP – Water outlet 35°C
- 6.1
- SCOP – Water outlet 55°C
- 3.78
- Min. sound pressure dB(A)
- 44
- Dimensions (mm)
- 770 x 1250 x 362
